poorgrad

An autodiff compiler stack in miniature, written the way Rust wants it written: record a graph once, inspect every node, lower it to a plan you can read, verify every optimization against the interpreter that ships inside — and emit StableHLO when you want the XLA world's muscle. Small enough to learn from; rigorous enough to catch a vendor compiler computing GPT-2 wrong.

poorgrad begins from Karpathy's micrograd and then takes the road the others don't: no Rc<RefCell<...>>, no single-threaded assumption, no graph rebuilt on every pass, and a payload generic over scalars and tensors alike. Sharing a computation graph across threads is not a feature bolted on with locks; it is what the types guarantee.

Where micrograd teaches autodiff by being small, poorgrad also teaches what an ML compiler does. Eager frameworks hide the graph — the schedule is the program; lazy frameworks hide the schedule — the graph is whatever the scheduler did. poorgrad shows both and lets you diff them: the tape is the specification, a compiled Plan is the schedule, Plan::describe() prints every decision — dead-node elimination, buffer liveness, fusion, rematerialization — and one assert checks any of them against the interpreter, bit for bit.

The discipline is the product: no dependency doing poorgrad's own work, #![forbid(unsafe_code)] unless you opt into the FFI backends — whose unsafe is scoped by a crate-wide deny, argued block by block, and small enough to audit in one sitting — shape errors surfaced when an expression is recorded, before anything runs, seeded runs bit-identical forever with golden-bit tests holding the line, and a suite on dual-platform CI that checks the hardware paths down to the last bit.

The bet

Most autograd engines are define-by-run: the graph is built dynamically as code executes, mutated in place, and single-threaded by assumption. poorgrad goes the other way, and everything below follows from that one choice:

• Record once, run anywhere. Expressions record a static tape; forward replays an O(1) snapshot of it, and backward replays the evaluation's own copy, so runs never lock the graph and never disturb each other. Declared inputs take per-run payloads through forward_with — feeds are run state, not graph state — so one shared network serves any number of threads, each feeding its own data and differentiating its own target.
• The tape is the spec; a Plan is the schedule. compile lowers the recorded graph into an execution plan — dead-node elimination against declared targets, buffer liveness, pattern fusion (the canonical im2col chain of a convolution executes as one window-GEMM call, never materialized), and opt-in rematerialization that trades backward time for memory — whose runs are bit-identical to the interpreter's and survive every generation of a training run. Every optimization's default was set by measurement, and where a trade did not always win it is a labeled option, never silent behavior. Plan::describe() prints the decisions, and the naive interpreter ships forever as the executable oracle every plan is tested against.
• Values are Copy. A Value is a borrow of its network plus a position: operators never consume their operands, handles cross threads freely, and a value outliving its graph is a compile error, not a bug report. Every type's Send + Sync contract is asserted at compile time.
• Mutation is a state transition. A gradient step produces the next network generation in O(parameters): the parameter store is rebuilt, the recorded structure is shared untouched through an append-only arena, replaced payloads are reclaimed with their generation, and older generations stay fully usable. Snapshot isolation, for networks.
• Performance falls out of structure. One Mutex in the engine itself, taken briefly per operation — the arena inside cow_vec holds the only other, and training never touches it; O(1) forks; dense matrix products on a slice path shaped for the compiler's auto-vectorizer — tens of GFLOP/s on Apple Silicon, bit-identical to the logical definition — with a documented seam (Elementary::gemm over a GemmTask) through which an element type can route dense products to its own kernel; no unsafe in the default build, with #![forbid(unsafe_code)] keeping it a promise rather than a claim (the optional backends open only their own scoped modules; the arena's unsafe core is cow_vec's, encapsulated behind its tested interface). CPU-only by default, on purpose: the engine is the point — and the claims are measured, not asserted: cargo bench runs the suite.

Acceleration

Opt-in cargo features route dense math to the hardware you already own: accelerate (the AMX/SME matrix units through cblas, vForce for whole-buffer transcendentals) and metal (the crate's own simdgroup GPU kernels) on a Mac, and simd (tuned CPU microkernels with runtime AVX-512/AVX2/NEON dispatch, measured 96 GFLOP/s f32) on Linux and everything else. Enabling a feature is the whole activation — the same training source spans a factor of four thousand, from the 0.4 GFLOP/s naive definition to AMX's measured 1.6 TFLOP/s f32, with zero source changes:

cargo run --release --features simd --example throughput
cargo run --release --features accelerate,metal --example throughput

What each build supports, how routing and determinism work, and every measured number: ACCELERATION.md.

Emission

A compiled forward plan is a closed, pure tensor function, and Plan::emit_stablehlo writes it down as a textual StableHLO module — the exchange dialect of the XLA world. The whole op set lowers, matched convolution chains raise to stablehlo.convolution, and every emitted module is checked twice against toolchains the crate never links: an external parser must accept the text, and the StableHLO reference interpreter must reproduce the interpreter's own results (tools/, driven by two environment variables the test suite honors).

On the emitted path, performance is XLA's and correctness is still ours to check. Measured both ways: the same tape serves a convolutional forward eleven times faster by handing the emitted plan to XLA-CPU, and the gpt2 example generates at 132 ms/token through XLA against the tape's 195, reproducing its text exactly — while Apple's experimental Metal plugin ran the same module at 26 ms/token and wrong, a verdict provable because the tape, XLA-CPU, and the reference interpreter agree with each other. Training, inspection, and the determinism contract stay at home. The numbers and their readings: ACCELERATION.md.

Notebooks

The crate runs in Evcxr, the Rust Jupyter kernel, with no wrapper API: Network::leaked() hands back a &'static Network so recorded proxies survive a cell boundary, and the rest is the ordinary crate.

:dep poorgrad = { version = "0.10", features = ["evcxr"] }
use poorgrad::*;

let mut network: &'static Network<f64> = Network::leaked();
let w: Value<'static, f64> = network.parameter(0.0);

The evcxr feature also draws poorgrad's own types as cell output — tensors as tables or heatmaps, gradients as a norm profile along the tape, and a Plan as its whole schedule with the live volume plotted beside it. Nothing about the core API changes: the feature adds inherent methods to existing types and no new vocabulary, and the charts come from the same malevich renderer the examples use.

The idiom, what leaking costs, and the rough edges: NOTEBOOKS.md.

Where it fits

• Learning what an ML compiler does. The examples are a curriculum: chained scalar expressions, the makemore acts, LeNet on MNIST, a VGG-style convnet on CIFAR-10, a one-block transformer, and GPT-2 with the released weights — every stage of the stack (recording, differentiation, plans, fusion, rematerialization, emission) landed with a consumer that uses it and a measured number that grades it. TERMINOLOGY.md keeps the vocabulary honest, and Plan::describe() makes optimization something you read, not something you trust.
• Systems research at legible scale. The IR is ~30 documented operations; a new pass, transform, or numeric idea can be tried in a day and graded against a built-in bitwise oracle on real consumers. The stack is small enough to hold in your head and rigorous enough that a disagreement means something.
• Reproducibility as a requirement, not a hope. No rand, no clocks, seeds all the way down: a model trained in CI is evidence, a rerun experiment is a checksum, and a regression bisect converges, because two identical runs cannot differ.
• Scientific and financial fitting in f64. First-class double precision with hardware acceleration behind it — 550 GFLOP/s measured through the accelerate feature — for calibration, curve fitting, and gradient-based optimization where f32 rounding is a liability. Accelerated f64 is the exception, not the rule, in ML stacks.
• Rust services that learn in production. Train, fine-tune, or calibrate dense models inside the process that serves them, without a Python runtime or a model file crossing a process boundary. Runs never lock the graph: one shared network answers inference on every thread while a training loop steps generations in the background, and parallel what-ifs ride O(1) forks — the threaded example, not an architecture project.

A taste

use poorgrad::Network;

let network = Network::new();
let w = network.parameter(0.0_f64);
let x = network.input(0.0);
let y = network.input(0.0);

// Operators record the graph; values are `Copy` and never consumed.
let error = w * x - y;
let loss = error * error;

let w_symbol = w.symbol();
let x_symbol = x.symbol();
let y_symbol = y.symbol();
let loss_symbol = loss.symbol();

// The graph is recorded once; every step feeds one sample of the line
// `y = 2 * x` and steps to the next generation, which shares the recorded
// graph while replacing the parameter payloads.
let samples = [(1.0, 2.0), (2.0, 4.0), (3.0, 6.0)];
let mut network = network;
for step in 0..100 {
    let (sample_x, sample_y) = samples[step % samples.len()];
    let loss = network.resolve(loss_symbol);
    let evaluation = network.forward_with([(x_symbol, sample_x), (y_symbol, sample_y)]);
    let gradients = evaluation.backward(loss);
    network = network.update(&gradients, |w, g| w - 0.02 * g);
}

let learned = network.resolve(w_symbol).payload().unwrap();
assert!((learned - 2.0).abs() < 1e-6);

The threaded example goes further: per-sample gradients computed on separate rayon threads over one shared network, then three learning rates trained in parallel on O(1) forks.

What's inside

The engine builds, evaluates, differentiates, and trains computation graphs over a generic payload — scalars or tensors alike. The complete machinery is grouped into private payload, engine, and neural modules while the crate root keeps the public API flat. From tape to training:

• Value — a Copy proxy to a value allocated in a Network, and the only graph handle in the public API. It borrows the network, so it cannot outlive it. Arithmetic operators build the graph (let x = v1 + v2; allocates a new computed node on the same network) and never consume their operands.
• Network — the single owner of the state of every value of a graph, backed by the arena-based cow_vec crate: allocation is append-only, cloning forks the network in O(1), and the whole structure is Send + Sync. A gradient step is a state transition: update produces the next generation, rebuilding only the parameter store while sharing everything else — replaced payloads drop with that generation, so a linear train loop does not retain weights per step. Structure lives in the shared arena: train-only forks stay clean, but nodes recorded on a sibling after clone can pin arena memory until every sharer drops; Network::compacted rebuilds private arenas from the live nodes when that trade must be unwound. input declares a per-run input with a default payload; forward_with binds fed payloads to inputs for one run, validated against their recorded shapes; forward_for additionally slices the run to the ancestors of declared targets, so a tape carrying several expressions (a training batch and an evaluation twin) evaluates only the one the run is for — reads of skipped values fail loudly rather than answer with a placeholder.
• Symbol — a detached, Copy identifier for a value. Network::resolve turns it into a proxy in a compatible generation, while rejecting unrelated or divergent networks. Training loops keep symbols of the loss and parameters across update steps.
• Evaluation and Gradients — the per-run results of forward and backward, read back with the same Value proxies that built the graph. Runs never mutate the network, so any number of them can execute concurrently.
• Plan — a compiled execution schedule derived from the tape by Network::compile (forward-only: aggressive buffer liveness, refuses backward), compile_training (retain-all, exact gradients), or compile_training_compact (drops large intermediates and rematerializes them during backward, bit-exactly). Plans fuse recognized patterns — matching is structural, so hand-written compositions fuse identically to facade-recorded ones, and keep-set values are fusion barriers — and describe() renders the whole schedule: liveness spans, drop sets, fusion groups, and the static live-volume story.
• Field — a value-aligned buffer tied to a network lineage rather than one generation, with elementwise algebra (+, scale, zip, map). Gradients is an alias for it: the field one backward run produces, combined across runs and carried across generations as optimizer state (momentum, Adam) with no conversion; update takes a compatible field covering the current graph as its update direction.
• Tensor — the built-in tensor payload: an immutable runtime shape over a shared element buffer read through a strided layout, so transpose and the broadcasts are O(1) views rather than copies (tensors are immutable, so aliasing a buffer is always safe). Its storage is an extensible representation — a dense Arc-shared buffer, a non-allocating constant, or a compact one-hot selection today, with room for more — and elements are read with iter, as_slice, or to_vec. A Network<Tensor<f64>> uses the same graph, evaluation, differentiation, and update APIs as a scalar network. The Tensorial trait provides matmul, transpose, the reductions sum and sum_along, the explicit broadcasts broadcast_like and broadcast_along, the window pair unfold/fold behind convolution and pooling, and the fused windowed_product the plan tier's window-GEMM pattern executes (scalars implement scalar semantics for the same trait bound). Broadcasting is explicit by design: a single value spread across a named reference's shape, or a payload repeated along one named axis — never an implicit alignment rule. Shapes are inferred and checked when expressions are recorded — a shape mismatch panics at the offending line, before anything runs: the record-once answer to type-level shape checking.
• Tape — internal: the append-only record (a Wengert list) shared by a network and all of its proxies, and the engine's single synchronization point.
• Function — internal: a statically sized enum of the differentiable operations, each variant owning its parameters and implementing the Operation trait (forward math and gradient routing per operation, dispatched with a plain match); operand links live in the tape's parallel operand column.
• Neuron — a scalar-granularity affine unit with weights, a bias, and an Activation. Its parameters are allocated on the network and retained as symbols across compatible generations.
• Layer — a dense layer at tensor granularity: activation(x.matmul(w) + b) over a [batch, inputs] value, one weight matrix and one bias vector, with the bias explicitly broadcast over the batch axis.
• Mlp — dense layers described by a sequence of widths such as [3, 4, 4, 1]: tanh hidden layers, an affine output, and caller-controlled initialization from each parameter's requested shape.
• BatchNorm — batch normalization over [batch, features] values: express normalizes by the batch's own statistics and returns them for running-estimate upkeep, while express_with normalizes by statistics fed per run — the training and inference modes of one layer, with the running estimates living in the training loop rather than on the tape.
• LayerNorm and RmsNorm — the stateless normalization siblings: per-sample statistics along the feature axis (standardize plus affine, or root-mean-square re-scaling alone), so there are no running estimates and one recorded expression serves training and inference alike.
• Conv2d — 2-D convolution over [batch, channels, height, width] values as a composed formula, not a primitive: padding, two sliding-window unfolds, and an im2col reshape route the whole computation into one rank-2 matmul on the accelerated GEMM path, and the gradient falls out of the chain rule. Torch-shaped [filters, channels, kh, kw] weights; stride and symmetric zero padding.
• max_pool and average_pool — spatial pooling over the same window view: the average via mean_along, the maximum via a left-biased maximum fold whose ties route deterministically to the earliest window position.
• cross_entropy — the classification loss as a composed formula over the fused, numerically stable Value::log_softmax: the mean negative log-likelihood of one-hot (or soft) targets, fed per run like any other input.
• Optimizer — the training-step strategy as an open, object-safe trait: Sgd (stateless), Adam (moments as Fields, bias correction exact via carried powers), and AdamW (decoupled decay, sparing rank-one parameters by default, any other policy via a predicate). Steps are pure field algebra, so identical runs are bit-identical, and gradients from a compiled plan drive the same trajectory as the engine's backward.
• init — deterministic, explicitly seeded initializer factories (uniform, normal, the fan-aware xavier and kaiming, and the gain-parameterized scaled behind them — pair it with any Activation::gain()) producing the shape-to-payload closures Layer and Mlp take, with no rand dependency: seeded runs stay bit-identical forever.

The name

A poor man's autograd: no GPU required, none wanted — and the poor, it turns out, were sitting on a matrix coprocessor the whole time. The name is the only modest thing about the design.

Terminology

The vocabulary used across code and docs — the scientific meaning of each term and its mapping to the Rust types — is collected in TERMINOLOGY.md.

Examples

• chain — build a small expression graph by chaining Value proxies with arithmetic operators, then evaluate it and compute gradients: cargo run --example chain.
• gradient_descent — fit w * x + b to a line, threaded with rayon: one shared network differentiated for per-sample targets on separate threads, then trained in parallel on O(1) forks, one per learning rate: cargo run --example gradient_descent.
• mlp_xor — train a tanh MLP on XOR at tensor granularity: the graph is recorded once, and every training step feeds a different minibatch through forward_with while the tape never grows: cargo run --example mlp_xor.
• makemore_bigram — train a character-level bigram language model on names and sample new ones: a [vocab, vocab] logit table read by gather, scored by cross_entropy, fed one-hot minibatches per run, and sampled through the composite softmax: cargo run --example makemore_bigram.
• makemore_mlp — the Bengio-style sequel: a three-character context embedded by gather, flattened by reshape, and pushed through a tanh hidden layer hand-rolled from raw parameters, with a single-row twin expression of the same parameters recorded for sampling. Beats the bigram's loss: cargo run --release --example makemore_mlp.
• makemore_mlp_facade — the same model with the hand-rolled layers replaced by Mlp; matching seeds make it train bit-identically to makemore_mlp, demonstrating that the facade is packaging, not different math: cargo run --release --example makemore_mlp_facade.
• makemore_mlp_compiled — the same model with its backward pass recorded: Network::differentiate appends the chain rule to the tape, one forward-only plan compiles loss and gradients together, and every training step is a single plan run with no backward pass. Matching seeds make it train bit-identically to makemore_mlp, at a lower memory peak — the plan's liveness frees what the gradient no longer needs: cargo run --release --example makemore_mlp_compiled.
• mnist — a LeNet-style convolutional network on MNIST: two conv/relu/max-pool stages and a dense head, every convolution one im2col + GEMM under the hood. Downloads and caches the four IDX files on first run, then reports test accuracy, per-step time, and the loss chart: cargo run --release --example mnist.
• cifar10 — a three-stage VGG-style convnet on real 32x32 color images, the plan tier's pressure consumer: a training plan compiled once serves every generation, and the forward-only probe plan's liveness keeps the 500-image accuracy probe's footprint flat. Downloads and caches the binary archive on first run: cargo run --release --example cifar10.
• makemore_mlp_batchnorm — makemore's third act: the same MLP with the hidden preactivation batch-normalized before the tanh (and its bias retired in favor of the learned shift). The training plan keeps the batch statistics readable so the loop can fold them into running estimates — plain payloads, fed to the single-row sampling twin per draw. At this shallow depth the final loss matches the plain MLP, as it should: the norm buys robustness to initialization, not loss: cargo run --release --example makemore_mlp_batchnorm.
• makemore_transformer — the attention act: a one-block pre-norm transformer over eight characters of context. The batch packs its samples into one token row so each head's attention is a single rank-2 matmul pair under a block-diagonal causal mask; heads join through concat, prediction rows come back through a one-hot gather, and RmsNorm feeds both residual branches. Beats the MLP acts' loss on the same last-position metric: cargo run --release --example makemore_transformer.
• makemore_mlp_parallel — the same model trained data parallel: each step fans its minibatch out as eight shard-sized runs on the shared network and averages the gradient fields, cutting the wall clock several-fold while computing the same batch gradient: cargo run --release --example makemore_mlp_parallel.
• makemore_embedding_map — the MLP with a two-dimensional embedding, drawn in the terminal before and after training by a hand-rolled labeled scatter chart: watch the vowels drift into their own cluster: cargo run --release --example makemore_embedding_map.
• gpt2 — text generation with OpenAI's released GPT-2 (124M) weights, the whole model recorded from the existing op surface: twelve pre-norm blocks of per-head attention under a causal mask, GELU held as scalar leaves, the tied head as the transposed embedding table, and one fixed-context sampling plan fed the token window per step. The checkpoint and tokenizer (byte-level BPE, hand-rolled like every algorithm an example exists to show) download and cache on first run. A third argument picks the engine: tape runs the plan at home, xla emits it as StableHLO and serves generation through a resident XLA process — measured faster than the tape and reproducing its text: cargo run --release --features accelerate --example gpt2 -- "Once upon a time" 40 xla. The full guide — engines, setup, the Metal cautionary tale — is examples/gpt2/README.md.
• throughput — the acceleration ladder measured on a wide dense model: raw 2048-square products and whole training steps, with the dimensions shrinking eightfold when no backend is compiled in: cargo run --release --features accelerate,metal --example throughput (or --features simd off macOS).

Contributing

Issues and pull requests are welcome — bug reports, feature ideas, questions, confusing-documentation reports (those are bugs too), and benchmark numbers from your machine all help. For larger changes, opening an issue first is appreciated: designs here are decided by measurement and written down before code, and a short conversation up front saves reworking a PR. CI expects cargo fmt, cargo clippy --all-targets -- -D warnings, and cargo test to pass; matching that locally is the whole checklist.

License

Licensed under either of MIT or Apache-2.0 at your option.
